The Administration command line interface (CLI) is the primary tool used to manage your store. It is used to configure, deploy, and change store components. It can also be used to verify the system, check service status, check for critical events and browse the store-wide log file. The command line interface is accessed using the following command :
"java -jar <kvhome>/lib/kvstore.jar <command>"
For a complete listing of all the commands available to you in the CLI,see CLI Commands and Subcommands in the Oracle NoSQL Administration Guide here
The Administration Console
Oracle NoSQL Database provides an HTML-based graphical user interface that you can use to monitor your store. It is called the Admin Console. To access it, you point your browser to a machine and port where your administration process is running. The Admin Console offers the following main functional areas :
Topology. Use the Topology feature to see all the nodes that have been installed for your store. See, the details about Replication Nodes in a shards and Storage Nodes You can view the health of shard view single console along with
Plan and History : View the plans and history of last 20 plans that have been executed.
Logs : View the logs files as well as download the log files to triage or debug issues.
Oracle NoSQL Database allows Java Management Extensions (JMX) or Simple Network Management Protocol (SNMP) agents to be optionally available for monitoring, in addition to the native monitoring provided by the Admin CLI and the Admin Console. These agents provide interfaces on each storage node that allow management clients to poll them for information about the status, performance metrics, and operational parameters of the storage node and its managed services, including replication nodes and admin instances.The JMX interface can be enabled in either the Community Edition or the Enterprise Edition. To use SNMP, however, you must have the Enterprise Edition.
The JMX service exposes MBeans for the three types of components. These MBeans are the java interfaces StorageNodeMBean, RepNodeMBean, and AdminMBean in the package oracle.kv.impl.mgmt.jmx. For more information about the status reported for each component, see the javadoc for these interfaces.
Additonally, there's also Integration with Oracle Enterprise Manager (OEM) that provides a graphical management interface tool to discover and monitor a deployed store. Refer to the guide for details about integration
